2pcs SI5351 Clock Signal Generator Module 0-150MHz 1Hz Resolution I2C Interface
En stock
0.20 kg
No
Nuevo
Amazon
- 【Programmable Clock Module】 Three independent LVCMOS outputs (CLK0/CLK1/CLK2); 2.5 kHz to 200 MHz frequency range; ±0 ppm accuracy via PLL fractional synthesis; Suitable for FPGA and MCU clocking applications
- 【Low Power Consumption】 Operating current ≤22 mA at 3.3 V; standby current ≤1 µA in deep sleep mode; supports 2.25–3.6 V core supply and 1.8–3.3 V output voltage; suitable for portable and low-power systems
- 【Robust I²C Interface】 I²C communication (address 0x60); 100–400 kbps data rate; built-in crystal oscillator (25 or 27 MHz); compatible with for Arduino, for Raspberry Pi, and STM32 platforms
- 【EMI-Resistant Design】 Programmable spread spectrum modulation (SSM) reduces electromagnetic interference; separate VDD and VDDO power supplies for noise isolation; operates reliably in industrial Settings (-40°C to +85°C)
- 【Easy Configuration and Integration】 Glitch-free frequency switching; no calibration drift; simple register setup via I²C; includes detailed pinout and configuration guide for quick deployment in digital systems
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
Conoce más detalles
Product Parameters Input Voltage (Core VDD): 2.25V–3.6V DC Output Voltage (VDDO): 1.8V–3.3V DC Output Frequency Range: 2.5 kHz–200 MHz Output Channels: 3 (CLK0/1/2, LVCMOS, 50Ω Impedance) Frequency Accuracy: ±0 ppm Jitter: Reference Clock: Built-In Crystal Driver (25/27 MHz External Crystal) Operating Current: ≤22 mA (VDD = 3.3V) Standby Current: ≤1 μA (Deep Sleep Mode) Temperature Range: -40°C to +85°C Communication Interface: I²C (Address 0x60, 100–400 kbps) Package: MSOP-10 🔌 Main Pin Functions VDD: Core Power (2.25V–3.6V). Decouple with 0.1 μF ceramic capacitor (≤5 mm from pin). VDDO: Output Drive Power (1.8V–3.3V). Use independent filtering (10 μF electrolytic + 0.1 μF ceramic capacitor). GND: System Ground. Requires single-point grounding (PCB copper area ≥80%). SDA/SCL: I²C Data/Clock Lines (open-drain). Use 4.7 kΩ pull-up resistors to VDD (trace length ≤10 cm, length deviation ≤2 mm). CLK0/1/2: LVCMOS Outputs. Limit load capacitance ≤10 pF ⚡ Key Features Multi-Channel Independent Synthesis: Dynamically configure 3 outputs (2.5 kHz–200 MHz) via I²C to replace crystals/VCXOs/PLLs. Glitch-Free Frequency Switching: Real-time adjustment without signal interruption (Suitable for frequency-hopping systems). Anti-Interference Design: Programmable spread spectrum modulation (SSM) suppresses EMI; separate VDD/VDDO pins enable noise isolation. Plug-and-Play: Direct square wave output compatible with FPGA, MCU, and RF digital systems.
