MusRock 2pcs 5A AC Current Detection Module 5V Relay - ±1% Accuracy 20Hz–400Hz, -40°C~85°C - 5A 250V AC Relay - Compatible with STM32 LabVIEW
Detalles del producto
Disponibilidad
En stock
En stock
Peso con empaque
0.20 kg
0.20 kg
Devolución
Sí
Sí
Condición
Nuevo
Nuevo
Producto de
Amazon
Amazon
Viaja desde
USA
USA
Sobre este producto
- 1. Product Parameters Input Voltage: DC 5V ±5% (3.5V–5.5V Range) Current Range: AC 0.3A–5A (±1% Accuracy) Response Frequency: 20Hz–400Hz (50/60Hz Optimized) Output Signal: Relay Switch (NO/NC/COM) Trigger Threshold: Adjustable via Potentiometer (0.3A–5A) Operating Temp.: -40°C to +85°C (Reliable) Relay Contact Rating: 5A@250VAC, 5A@30VDC 2. Key Pin Functions Power & Control VCC: DC 5V Input GND: Power/Signal Ground Relay Terminals COM: Relay Common Terminal (Connect to load power) NC: Normally Closed (Closed when relay disengaged) NO: Normally Open (Closed when relay engaged) ⚠️ Critical Notes: COM-NO/NC max current: 5A (Exceeding causes contact welding) VCC-GND reverse voltage >0.5s damages LM393 comparator 3. Common Issues & Solutions Q1: Relay chatters/noisy operation? Cause: EMI from motors/transformers → Relocate module >10cm away Fix: Add 100nF ceramic capacitor between VCC/GND Q2: Fails to trigger at set threshold? Calibrate: Rotate potentiometer clockwise until relay clicks, then test with 0.5A load Check: Wire diameter ≤5.2mm (thicker wires reduce sensitivity) Q3: False triggers at high temps (>70°C)? Cause: LM393 thermal drift → Recalibrate threshold at operating temperature Mitigation: Add heatsink to LM393 chip (thermal tape recommended) Q4: COM/NC/NO contacts overheat? Verify: Load current ≤5A → Use external relay for >5A loads Upgrade: Replace with silver-alloy contacts (model AGN210)
$24,94
44% OFF
$13,86
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
$24,94
44% OFF
$13,86
20% OFF adicional al pagar con Deuna
Envío gratis
Llega en 5 a 12 días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Conoce más detalles
【High-Precision AC Current Detection】 5A overcurrent protection sensor module; 0.3A to 5A detection range; ±1% accuracy; 20Hz to 400Hz frequency response 【Adjustable Threshold Control】 Potentiometer-adjustable trigger level from 0.3A to 5A; easy calibration for accurate protection; suitable for home and small industrial applications 【Robust Relay Output System】 5A@250VAC relay contacts; NO/NC/COM terminals for flexible circuit control; compatible with common microcontroller systems 【Wide Operating Temperature Range】 -40°C to +85°C operation; 0-95% RH tolerance; Suitable for outdoor or variable Enviro nment use 【Easy Installation & Reliable Performance】 3mm mounting holes; 52.5mm spacing; 5.2mm maximum wire diameter; low power consumption <20mA; stable performance under normal conditions
