Artículo: AMZ-B0B1HPDT8H

Jessinie

Signal Generator XY-KPWM 1-Channel PWM Generator 1Hz-150kHz Dual Mode PWM Pulse Frequency Square Wave Signal Generator Module LCD Display 3.3-30V 5-30mA Pulse Frequency Generator with Shell

Disponibilidad
En stock
Peso con empaque
0.20 kg
Devolución
Condición
Nuevo
Producto de
Amazon

Sobre este producto
  • XY-KPWM Signal Generator has two working modes to choose from, the frequency range of the normal mode is 1Hz-150kHz, and the duty cycle is stepped by 1%; the fine mode frequency range is 1Hz-15kHz, and the duty cycle is stepped by 0.1%
  • PWM Generator use potential encoder to adjust, simple, convenient and easy to use; LCD liquid crystal display, clearly display frequency and duty cycle, PWM with switch, can turn on and off PWM output with one key
  • Pulse generator PWM output can set frequency and duty cycle respectively; Adjust the upper and lower limits of duty cycle freely
  • With locking function, prevent misoperation, all setting parameters, power-down storage, high frequency range, high precision, serial communication is acceptable
  • Widely used as a square wave signal generator to generate square wave signals for experimental development and use. Used to generate square wave signals for controlling motor drivers; Generate adjustable pulses for MCU use; Generate adjustable pulses and control related circuits (applications such as PWM dimming and speed regulation), etc
$46,73
60% OFF
$18,69

IMPORT EASILY

By purchasing this product you can deduct VAT with your RUT number

$46,73
60% OFF
$18,69

Difiere a 3 y 6 meses sin intereses con Diners, Discover y Titanium

Envío gratis
Llega en 5 a 12 días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja de USA a tus manos en
Medios de pago Tarjetas de Débito, Crédito y Deuna

Compra protegida

Disfruta de una experiencia de compra segura y confiable
