Microcontroller Solder Adapter Compatible with Most PIC24 & PIC32 SOIC-28 Devices, Includes PicKit Programming Header Pins and Required Capacitors Pads - (Board Only, PCB Parts Not Included)

Conoce más detalles

Modular breakout boards such as these include an SMT adapter (SOIC-28), an integrated PicKit programming header (PicKit not included), spare solder holes, and all required passive component pads in a single reusable SMD breakout board. Compatible with a wide range of SOIC 28-pin PIC devices including most PIC-24 and PIC-32 devices. Please see posted schematic to verify your specific device. Please confirm: (Pin 1=MCLR), (Pin 4 =PGD), (Pin 5=PGC), (Pins 13,28=VDD), (Pins 8,27=COM), and (PIN=VCAP) Dual Rows of solder pin holes provides much more flexibility in soldering and mounting your circuit. Jumper wires can also be soldered between holes, reducing number of breadboard connections. Oversized Solder Pads simplify hand soldering. Can be easily soldered without special equipment in as little as a few seconds. See our website for easy soldering tips. 0603/0805 Footprint Pads between each pin and the local common plane (or pin to pin) allow for integrated onboard SMT res/cap connections, greatly reducing the number of wired connections.
