seeed studio Grove - CO2 Sensor
En stock
0.30 kg
Sí
Nuevo
Amazon
USA
- The Grove - CO2 Sensor module is infrared CO2 sensor high sensitivity and high resolution. Infrared CO2 sensor MH-Z16 Is a general-purpose, small sensors , the use of non-dispersive infrared (NDIR) Present in the principle of the air CO2 Detect , with good selectivity, oxygen- dependent , long life£¬ built-in temperature sensor, temperature compensation £¬with UART output , easy to use. It can be widely used in HVAC and indoor air quality monitoring , industrial process monitoring and security , agriculture and livestock production process monitoring. Specification: - Measuring the range of 0-2000 parts per million (PPM) - Resolution of 1 PPM 0-2000 parts per million (PPM) - Accuracy of 200 PPM - A Warm - up time 3 minutes - Response Time <90s - Operating temperature 0 to 50¡æ - Operating Humidity 0% ~ 90% RH - Storage temperature - 20-60¡æ - Operating Voltage4.5 V to 6 V DC - The Current maximum Current of less than 100 ma, the average Current of less than 50 ma - Output mode UART
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
Conoce más detalles
Measuring the range of 0-2000 parts per million (PPM). Resolution of 1 PPM 0-2000 parts per million (PPM). Accuracy of 200 PPM. A Warm- up time 3 minutes. Response Time <90s. Operating temperature 0 to 50¡æ. Operating Humidity 0% ~ 90% RH. Storage temperature- 20-60¡æ. Operating Voltage4.5 V to 6 V DC. The Current maximum Current of less than 100 ma, the average Current of less than 50 ma. Output mode UART.
