SKU/Artículo: AMZ-B007ZQLJ3O
KB Electronics
KBIC-120 (9429) DC Drives Chassis
Detalles del producto
Disponibilidad:
En stock
En stock
Peso con empaque:
0.30 kg
0.30 kg
Devolución:
Sí
Sí
Condición
Nuevo
Nuevo
Producto de:
Amazon
Amazon
Viaja desde
USA
USA
Sobre este producto
- THIS DRIVE WILL NOT OPERATE UNLESS A PLUG-IN HORSEPOWER RESISTOR THAT MATCHES YOUR MOTOR'S HORSEPOWER AND VOLTAGE IS INSTALLED. Horsepower resistors are sold separately. The KBIC-120 chassis-mounted DC drive is a 115 VAC rated 9 Amps RMS @ 45C. The control is designed for 90 VDC PM, Shunt and AC/DC motors. It will control motors between 1/100-1/2 HP (1.0 HP w/aux. Heat sink) by inserting the proper Plug-in Horsepower Resistor. Speed range is 50:1 with load regulation of 1%. Features include Auto Inhibit, Voltage Following, MOV transient protection, 5K speed pot and trimpot adjustments for Min, Max, Accel, IR and CL. Options include Auxiliary heat sink, AC Line and Armature Fuse Kit, Barrier Terminal Board, RFI/EMI filters and Signal Isolation (model SI-5). This control is available worldwide from stocking KB distributors. UL, CSA, CE. Patented.
S/ 940.91
60% OFF
S/ 376.37
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
S/ 940.91
60% OFF
S/ 376.37
Hasta 6 cuotas sin intereses con BCP, BBVA y Diners
Llega en 10 a 15 días hábiles
con envío
Tienes garantía de entrega
Conoce más detalles
KBIC-120 KB Electronics 115 VAC, thru 0 5 HP, 90 VDC ARM (9429) Plug-in Horsepower Resistor Required The control must have a Plug-in Horsepower Resistor installed; purchased separately Plug-in Line Fuse Optional Optional fuse mounting kit Plug-in Armature Fuses purchased separately The KB Electronics KBIC Controls PM, Shunt and AC/DC motors over a range of 1/100 - 3 HP with only a few models All models can be used on a wide range of motor horsepower by inserting KBs exclusive Plug-In Horsepower Resistor Speed range is 50:1 with load regulation of 1%
