ESP32-C6 2.06inch AMOLED Touch Watch Development Board, 410×502 Pixels, RISC-V 32-bit Processor, Supports Wi-Fi 6 / BLE 5 / Zigbee, ESP32 with Display, NOT Include Battery
Disponibilidad
En stock
En stock
Peso con empaque
0.20 kg
0.20 kg
Devolución
No
No
Condición
Nuevo
Nuevo
Producto de
Amazon
Amazon
Sobre este producto
- Adopts ESP32-C6 module with RISC-V 32-bit processor, up to 160MHz frequency. Integrated Wi-Fi 6, BLE 5 and IEEE 802.15.4 (Zigbee 3.0 and Thread) wireless communication, with superior RF performance.
- Built-in 512KB HP SRAM, 16KB LP SRAM, 320KB ROM, and 16MB Flash memory. Type-C connector, improving device compatibility, easier to use.
- Onboard 2.06inch AMOLED capacitive touch display for clear color picture display, 410 × 502 resolution, 16.7M color. Built-in CO5300 display driver and FT3168 capacitive touch chip, using QSPI and I2C communication respectively, effectively saving the IO resources.
- Onboard QMI8658 6-axis IMU (3-axis accelerometer and 3-axis gyroscope) for detecting motion gesture, counting steps, etc.. Onboard PCF85063 RTC chip, powered by Lithium Batt. through AXP2101 chip for uninterrupted power supply.
- Onboard PWR and BOOT programmable buttons for easy custom function development. Onboard 3.7V MX1.25 Lithium Batt. recharge/discharge header. Onboard reserved pads of 1 × I2C, 1 × UART and 1 × USB interfaces, for connecting peripherals and debugging.
- Adopts AXP2101 IC for efficient power management, supports multiple voltage outputs, BATT charging, BATT management, and BATT life optimization, etc.
- Adopts AMOLED screen, featuring advantages of high contrast, wide viewing angle, rich colors, fast response, thinner design, and low power consumption, etc.
$105,15
49% OFF
$53,92
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
$105,15
49% OFF
$53,92
Difiere a 3 y 6 meses sin intereses con Diners, Discover y Titanium
Envío gratis
Llega en 26 o más días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Compra protegida
Disfruta de una experiencia de compra segura y confiable
![]()
Garantía de entrega
Con Tiendamia todas tus compras cuentan con Garantía de Entrega o devolución total de tu dinero.
Compras 100% seguras y garantizadas, para que pidas lo que sueñas y lo recibas del mundo a tu puerta.
Tarjetas de Débito y Crédito
Visa
Mastercard
American Express
Dinners
Discover
Alias
Pagos a través de PayPal
Compra procesada en dólares con dinero en cuenta o tarjetas internacionales.
PayPal
Conoce más detalles
Features The ESP32-C6-Touch-AMOLED-2.06 is a high-performance, wearable watch-style development board designed by Waveshare. Based on the ESP32-C6 microcontroller, it integrates a 2.06inch AMOLED capacitive touch display, 6-axis IMU, RTC chip, audio codec chip, power management IC, and so on. Comes with a custom-designed case with a smartwatch-like appearance, making it ideal for prototyping and functional verification of wearable applications. AMOLED parameters ● Display Panel: AMOLED ● Display Size: 2.06 inch ● Resolution: 410 × 502 pixels ● Display Colors: 16.7M ● Brightness: 600 cd/㎡ ● Contrast Ratio: 100000:1 ● Communication Interface: QSPI ● Driver IC: CO5300 ● Touch: Supported ● Touch IC: FT3168 Package Content 1. ESP32-C6-Touch-AMOLED-2.06 x1 2. Watch straps ×1
