2Pcs DC 12v Delay Relay Module for Smart Home Delay Relay Switch with Time Timer Timing Adjustable Potentiometer 12V Delay Circuit Board Disconnection and Connection Function
Disponibilidad
En stock
En stock
Peso con empaque
0.20 kg
0.20 kg
Devolución
Sí
Sí
Condición
Nuevo
Nuevo
Producto de
Amazon
Amazon
Sobre este producto
- Load voltage: DC 30V or AC 250V, Load current: 10A
- Relay lifespan: over 100000 cycles
- Supply voltage: 12V; Static current:5.5mA
- Maximum operating current:42mA
- The module can be used in various control scenarios such as driving recorders, GPS start protection, household appliances, electronic device protection, PLC control, industrial control, electronic experiments, robots, etc
$32,09
55% OFF
$14,59
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
$32,09
55% OFF
$14,59
Difiere a 3 y 6 meses sin intereses con Diners, Discover y Titanium
Envío gratis
Llega en 5 a 12 días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Compra protegida
Disfruta de una experiencia de compra segura y confiable
![]()
Garantía de entrega
Con Tiendamia todas tus compras cuentan con Garantía de Entrega o devolución total de tu dinero.
Compras 100% seguras y garantizadas, para que pidas lo que sueñas y lo recibas del mundo a tu puerta.
Tarjetas de Débito y Crédito
Visa
Mastercard
American Express
Dinners
Discover
Alias
Pagos a través de PayPal
Compra procesada en dólares con dinero en cuenta o tarjetas internacionales.
PayPal
Conoce más detalles
The 12V delay relay module adopts relays with a maximum current of 10A. The module uses double-sided FR-4PCB board, and the overall layout of the module is reasonable, beautiful and generous. Using original high-performance delay chips for better performance. Equipped with a delay adjustment potentiometer, the shortest time is 0.1 seconds and the longest can reach 1 hour. It also has an anti reverse power protection diode, which can effectively protect the product. Maximum frequency of switch: 5KHz Product weight: approximately 22g Structural dimensions: 57 * 30 * 18.5mm (length * width * height) Positioning hole size: 52*25mm Interface Description 1. When it comes to modules When the S6 jumper cap is plugged in and the S7 is not plugged in, the module immediately starts timing (with an adjustable time range) as soon as the power is turned on. At the same time, the relay is immediately closed, and the common terminal of the relay is connected to the normally open terminal. After the delay ends, the relay is released, and the common terminal is connected to the normally closed terminal. 2. When the S7 jumper cap is plugged in on the module and S6 is not plugged in, as soon as the module is powered on, it immediately starts timing (with an adjustable time range). At this time, the relay does not close (not connected), the delay ends, the relay closes, and the common terminal and normal start are connected. Potentiometer adjustment time range S1:0, S2:1, Without S4:0.13-1.3s; With S4:1.5-14.5s S1:1, S2:0, Without S4:0.5-5.2s; With S4:6-58s S1:0, S2:0, Without S4:4.4-42s; With S4:48-463s S1:1, S2:1, Without S4:38-340s; With S4:389-3700s Reminder: When the relay controls AC 220V or other DC power supply voltages greater than VCC, the jumper cap S5 cannot be inserted. If S5 is inserted in this way, high voltage will flow back into the module, which will burn out the module.
