RS485 to RJ45 Ethernet Module, Rail Guide RS485 Converter Module, Support Rail-Mount/Modbus Gateway
Disponibilidad
En stock
En stock
Peso con empaque
0.20 kg
0.20 kg
Devolución
No
No
Condición
Nuevo
Nuevo
Producto de
Amazon
Amazon
Sobre este producto
- Small size: relative to the ordinary serial port server, the width is small, does not take up much space.
- Standard guide rail design: suitable for internal installation of cabinet in industrial field.
- Terminal type power supply, 9～24V wide voltage input, with anti-opposite power connection protection.
- Support TCP server side, TCP client, UDP mode, UDP multicast.
- Terminal RS485 interface, support 32 slave devices. Baud rate support 300～115200bps. The data bit supports 5~9 bits, and the parity can be none Checksum, odd checksum, parity, markup, spaces these five ways.
$44,14
31% OFF
$30,44
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
$44,14
31% OFF
$30,44
20% OFF EXTRA automáticamente al pagar con Deuna
Envío gratis
Llega en 16 a 26 días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Compra protegida
Disfruta de una experiencia de compra segura y confiable
![]()
Garantía de entrega
Con Tiendamia todas tus compras cuentan con Garantía de Entrega o devolución total de tu dinero.
Compras 100% seguras y garantizadas, para que pidas lo que sueñas y lo recibas del mundo a tu puerta.
Tarjetas de Débito y Crédito
Visa
Mastercard
American Express
Dinners
Discover
Alias
Pagos a través de PayPal
Compra procesada en dólares con dinero en cuenta o tarjetas internacionales.
PayPal
Conoce más detalles
Overview RS485 TO ETH RAIL is a kind of RS485 device collector/IoT gateway specifically designed for industrial environments, which is multi-functional, such as integrating serial server, Modbus gateway, MQTT gateway, RS485 to JSON. It features an RS485 interface and an Ethernet interface. It uses the guide-way type installation way, which is small and easy to install. Terminal type power supply access, 9~24V wide voltage input. Since there is only an RS485 interface, the RS232 interface, which is not commonly used on industrial instruments, is canceled, saving cost and volume, and is low-cost and higher performance ration compared with ordinary products. Specifications Communication Interface: Terminal, Network Port Power Supply:Terminal Maximum Size: L × W × H = 10.6cm × 3.6cm × 5.9cm Ethernet: RJ45 interface, 2KV surge protection Serial: RS485×1: RXD, TXD, GND Baud Rate: 300~115200bps Data Bits: 5~9 Parity: None, Odd Check, Even Check, Mark, Space Flow Control: None Protocol: ETHERNET、IP、TCP、UDP、HTTP、ARP、ICMP、DHCP、DNS Setting Method: VirCOM, WEB Browse, Device Management Library Communication Method: TCP/IP direct communicate, Virtual Serial Work Mode: TCP Server, TCP Client（coexisting with TCP serer), UDP, UDP multicast Power Voltage: 9~24V DC Running Temperature: -40~85℃ Package contents: RS485 TO ETH x1 Note: Power supply is not included, it is recommended to use a 12V Industrial DIN-Rail Power Supply. Please feel free to contact us via Amazon message if you have any problem.
