Taidacent Serial Port Control 0-10V Signal Converter RS232 to Analog Voltage Converter Modbus-Rtu Command Control Linear Output

Style:

0-10V

0-10V

0-5V

Disponibilidad
En stock
Peso con empaque
0.20 kg
Devolución
Condición
Nuevo
Producto de
Amazon

Sobre este producto
  • Board size: length 88mmX width 50mmX height 32mm
  • Analog voltage output: 0-5V and 0-10V. The default delivery is 0-10V
  • Working voltage: DC12V, DC24V can be used
  • Output voltage error: ±0.05V
  • Power consumption: the current is 32ma when the working voltage is 12V
$60,26
31% OFF
$41,56

IMPORT EASILY

By purchasing this product you can deduct VAT with your RUT number

$60,26
31% OFF
$41,56

Difiere a 3 y 6 meses sin intereses con Diners, Discover y Titanium

Envío gratis
Llega en 5 a 12 días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja de USA a tus manos en
Medios de pago Tarjetas de Débito, Crédito y Deuna

Compra protegida

Disfruta de una experiencia de compra segura y confiable

Conoce más detalles

Special statement: Please pay attention to the wiring, do not directly supply power to VOUT+ and VOUT- with the positive and negative of the power supply, otherwise the module will be burned out, be careful! If you connect the wrong cable and cause damage, please bear it yourself! Product parameters: 1. Board size: length 88mmX width 50mmX height 32mm 2. Analog voltage output: 0-5V and 0-10V. The default delivery is 0-10V 3. Working voltage: DC12V, DC24V can be used 4. Output voltage error: ±0.05V 5. Power consumption: the current is 32ma when the working voltage is 12V 6. Communication protocol: MODbus-RTU mode, other protocols can be customized, please contact us if you need it! 7. Communication parameters: baud rate 9600, n, 8, 1 Product function: Send commands through the serial port to control 0-10v analog voltage signal output (terminals Vout+, Vout-) 0x800 corresponds to 2048 in decimal, and the output voltage is 4.99v
