RLECS 2pcs Encoder Module Brick Sensor clickable Switch 360 Degree Rotary KY-040 with Knob Cap for Arduino
Disponibilidad
En stock
En stock
Peso con empaque
0.20 kg
0.20 kg
Devolución
Sí
Sí
Condición
Nuevo
Nuevo
Producto de
Amazon
Amazon
Sobre este producto
- Type: KY-040 Rotary Decoder Encoder
- Operating Voltage: 5V; One round number of pulse: 20
- Size: 30x19x28mm(LxWxH); Package: 2 x KY-040 Rotary Decoder Encoder
- No limitation on rotation counts
- The encoder can be reset to its initial state, that starts counting from 0 with the button on the rotary
$32,81
60% OFF
$13,13
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
$32,81
60% OFF
$13,13
Difiere a 3 y 6 meses sin intereses con Diners, Discover y Titanium
Envío gratis
Llega en 5 a 12 días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Compra protegida
Disfruta de una experiencia de compra segura y confiable
![]()
Garantía de entrega
Con Tiendamia todas tus compras cuentan con Garantía de Entrega o devolución total de tu dinero.
Compras 100% seguras y garantizadas, para que pidas lo que sueñas y lo recibas del mundo a tu puerta.
Tarjetas de Débito y Crédito
Visa
Mastercard
American Express
Dinners
Discover
Alias
Pagos a través de PayPal
Compra procesada en dólares con dinero en cuenta o tarjetas internacionales.
PayPal
Conoce más detalles
Specification: Type: KY-040 Rotary Decoder Encoder Operating Voltage: 5V One round number of pulse: 20 Width: 19mm Length: 30mm Height: 28mm Material of Knob Cap: Aluminium Alloy Diameter of Knob Cap: 14mm Height of Knob Cap: 17mm Package includes: 2 x KY-040 Rotary Decoder Encoder Pin description: CLK - equivalent to output A in regular encoder. DT - equivalent to output B in regular encoder. GND - equivalent to output C in regular encoder. SW - reset switch. + (VCC) - positive supply to the unit. The KY-040 rotary encoder is a 360 degree rotary input device (i.e. a control knob) that provides an indication of how much the knob has been rotated AND which direction it is rotating in. It is a great device for stepper and servo motor control. You can also use it to control devices like digital potentiometers. It is ideal for navigating menus on a display or taking inputs such as numbers or text characters. The range of input can be easily defined and mapped in software. A push button switch is built into this encoder. If you push on the shaft, the normally open switch "SW" will close. This can be used as an On/Off switch, to change control functions, ranges, selecting a menu item or entering a number. The "D" shaft of the encoder can be fitted with a knob for using it in a product.
