Heschen M12 Capacitive Proximity Sensor Switch Non-Shield Type LJC12A3-5-Z/BX Detector 1-5mm 10-30VDC 200mA NPN Normally Open(NO) 3 Wires
En stock
0.20 kg
Sí
Nuevo
Amazon
- Mounting Hole Diameter: 12mm
- Detecting Distance: 5mm±10%; Set distance: 0-4mm
- Output Type: NPN Normally Open(NO); Non-Shield Type
- Current Output: 200mA; Working Voltage: 10-30VDC
- Detect Object: Can detect any dielectric
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
Conoce más detalles
Detection Object:Can detect any dielectric.Delay Distance:10% below of the detection distance.Supply Voltage:DC10-30V Impulse (p-p)10% below.Comsuption Current:13mA below.Control Output: 200mA below.Loop Protection :reversal connection protection,surge absorption,load short-circuit protection.Ambient Temperature & Humidity:During operation , storage : individually-30~+65℃(no freeze ,no drew ) ,During operation,storage:individually 35-95%RH.Insulation Impedance :50MΩ above ( DC500 megameter ) between charging part and shell.Withstand Voltage : AC1000V 50/60Hz 1 min. between charging part and shell.Temperature Influence : Temperature range-30~+65℃,at + 23℃,± 15% detection distance, Temperature range-25~+60℃,at +23℃,±10% detection distance.Voltage influence : Inside ±I5% rated supply voltage range,at rated supply voltage value ,inside ± 10 % detection distance.Protection structure: IP67(IEC specification)
