SKU/Artículo: AMZ-B0FTFW81QV
MusRock
MusRock 10pcs AT24C32 32Kbit I2C EEPROM Memory Module Through-Hole
Color:
AT24C32 32Kbit
Detalles del producto
Disponibilidad:
En stock
En stock
Peso con empaque:
0.30 kg
0.30 kg
Devolución:
Sí
Sí
Condición
Nuevo
Nuevo
Producto de:
Amazon
Amazon
Viaja desde
USA
USA
Sobre este producto
- **AT24C32 I²C EEPROM Module – 32Kbit Non-Volatile Memory** - **Storage Capacity**: 32Kbit (4096 x 8 bit) - **Interface**: I²C/SMBus compatible (100kHz–400kHz) - **Voltage Range**: 1.8V–5.5V DC - **Write Endurance**: 1,000,000 cycles - **Data Retention**: ≥100 years - **Page Write Buffer**: 32 bytes - **Write Time**: 5ms typical - **Temp Range**: -40°C to 85°C (Industrial), 0°C to 70°C (Commercial) - **Package**: DIP-8 (2.54mm pitch) **Key Features** - Plug-and-play with for Arduino /STM32 - Hardware write protection via WP pin - Fast page write (3x speed) - Wide voltage compatibility - Reliable data storage for system settings **Pin Functions** - VCC: 1.8V–5.5V power supply - GND: Ground connection - SDA: Bidirectional data line (4.7kΩ pull-up required) - SCL: Clock signal input - A0/A1/A2: Address selection (up to 8 devices) - WP: Write protect (high = no write) **FAQ** Q: No response on I²C? A: Check pull-up resistors, VCC ≥1.8V, and address conflict. Q: Data lost after restart? A: Ensure WP is low, avoid page overflow, wait 5ms after write. Q: Slow writes? A: Use 32-byte buffer, enable fast mode (400kHz).
S/ 78.34
55% OFF
S/ 35.61
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
S/ 78.34
55% OFF
S/ 35.61
Hasta 6 cuotas sin intereses con BCP, BBVA y Diners
Llega en 5 a 10 días hábiles
con envío
Tienes garantía de entrega
Conoce más detalles
【High Capacity Storage】 32Kbit EEPROM module; 4096 x 8 bit organization; supports byte and page read/write operations; Suitable for system configuration storage and data logging. 【Wide Voltage Compatibility】 Operates from 1.8V to 5.5V DC; compatible with 1.8V, 3.3V, and 5V systems; no additional voltage regulation required for most applications. 【Fast I2C Communication】 I²C/SMBus compatible; supports 100kHz and 400kHz modes; 5ms write cycle time with self-timed mechanism; enhances real-time data recording performance. 【Easy Integration with Development Boards】 for for Arduino compatible; for for Raspberry Pi supported; pin layout matches standard DIP-8 format; easy to use with breadboards and development kits. 【Robust Write Protection and Data Retention】 1,000,000 write cycles guaranteed; 100 years data retention; WP pin enables hardware-level write protection; prevents accidental data loss in critical applications.
