DC 12V 3A Fan Speed Control Module with Sensor Cable for Computer Chassis, CPU and Many Server 4-Wire Fans
En stock
0.30 kg
Sí
Nuevo
Amazon
USA
- Parameter Description: power supply voltage:DC 12V Voltage range: DC 8~16V (Please note the fan voltage range for the circuit working voltage) Circuit self-consumption: less than 40mA(tested under 12V) Fan current: no more than 3.3A PWM range: 1%~100% (signal percentage not actual speed ±0.5%) PWM frequency: 25KHZ (+/-1KHZ) PWM Signal Amplitude: 5V Temperature Measurement Range: -9.9℃~ 99.9℃ Temperature Measurement Error: 0~50℃ less than 1.2℃; other temperature ranges less than 2℃ This speed controller only supports 4-wire PWM fans, not 2-wire and 3-wire fans. Package: 1x Module 1x Sensor cable
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
Conoce más detalles
1.Parameter:Supply Voltage: DC 12V. Voltage Range: DC 8~16V. 2.The fan speed control module is equipped with a temperature controller, which can automatically adjust the fan speed according to the actual temperature,when the temperature is too low, the fan can be stopped. 3.Suitable for computer chassis, CPU and many server 4-wire fans.(not support 2-wire and 3-wire fans). 4.Size:50x18.9mm/1.97x0.74inch (L*W); Sensor cable length : 410mm/16.1 inch. 5.Package: 1x Module; 1x Sensor cable.
