2Pcs STM32F411CEU6 Development Board STM32F4 Core STM32F411CEU6 Module System Board Learning Board 100Mhz Freq 128KB RAM 512KB ROM for Programming
Disponibilidad
En stock
En stock
Peso con empaque
0.20 kg
0.20 kg
Devolución
No
No
Condición
Nuevo
Nuevo
Producto de
Amazon
Amazon
Sobre este producto
- Experience the power of the ARM Cortex M4 with this STM32F411CEU6 Development Board, featuring a blazing fast 100Mhz frequency and zero-wait state access to 512KB ROM and 128KB RAM for seamless programming
- Unlock endless possibilities with the STM32F4 Core STM32F411CEU6 Module System Board, equipped with FPU floating-point unit for efficient calculations and a plethora of interfaces including USART, I2C, SPI, and USBFS for versatile connectivity options
- Dive into the world of embedded systems with this Learning Board, boasting 20 Pin 2.54mm I/O interfaces, 4 Pin 2.54mm SW debugging interface, and user-friendly buttons like KEY (PA0), NRST, and BOOT0 for convenient operation and development
- Stay powered up and connected with the 3.3V-5V power input, 3.3V LDO with a maximum output current of 100mA, and a USB-C interface with built-in diode to prevent power backflow, along with high-speed and low-speed crystal oscillators for reliable performance
- Elevate your programming projects with the STM32F411CEU6 Development Board, featuring a SPI Flash for additional storage options, 12-bit ADC, 12-bit 5 S for accurate measurements, and 32.768K 6pF low-speed crystal oscillator for precise timing control
$19,67
20% OFF
$15,73
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
$19,67
20% OFF
$15,73
Hasta 6 meses sin intereses con Pacificard, Diners, Discover y Titanium
$15 OFF con el cupón PRIME
Envío gratis
Llega en 5 a 12 días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Compra protegida
Disfruta de una experiencia de compra segura y confiable
![]()
Garantía de entrega
Con Tiendamia todas tus compras cuentan con Garantía de Entrega o devolución total de tu dinero.
Compras 100% seguras y garantizadas, para que pidas lo que sueñas y lo recibas del mundo a tu puerta.
Tarjetas de Débito y Crédito
Visa
Mastercard
American Express
Dinners
Discover
Alias
Pagos a través de PayPal
Compra procesada en dólares con dinero en cuenta o tarjetas internacionales.
PayPal
Conoce más detalles
ARM Cortex M4 Zui operates at a high frequency of 100MHz, with zero waiting for memory access FPU Floating Point Computing Unit storage 512KB ROM flash program memory 128KB SRAM Static Random Access Memory SPI Flash (solder mask) Interface and buttons USART x 3, I2C x 3, SPI x 5,USBFS x 1 ADC x 1(10),12S x 5,CRC x 1,TIM x 8 20 Pin 2.54mm spacing I/O interface x 2 4 Pin 2.54mm spacing SW debugging interface x 1 USBC (typeC) interface x 1 User key KEY (PAO) x 1 Reset button NRST x 1 BOOT0 button x 1 Clock and power supply: 3.3V-5V power input, 3.3V LDO MAX output current of 100mA Using USB-C interface and diodes in series to prevent power backflow 25MHzpF high-speed crystal oscillator 32.768K 6pF low-speed crystal oscillator
