High Precision Function Signal Generator DIY Kit XR2206 Adjustable Frequency Amplitude Module Sine Triangle Square Output 1Hz-1MHz DC 9-12V

Disponibilidad
En stock
Peso con empaque
0.20 kg
Devolución
No
Condición
Nuevo
Producto de
Amazon

Sobre este producto
  • Can generate sine waves, triangular waves, and square waves
  • The frequency can range from 1HZ-1MHz; Frequency and amplitude adjustable
  • Five bit precision resolution; Frequency adjustment has coarse and fine tuning
  • Wide power supply range, can use external power supply 9-12V or 9V batteries
  • All direct insertion components have a small number of components and are easy to install and debug.
$32,81
60% OFF
$13,13

IMPORT EASILY

By purchasing this product you can deduct VAT with your RUT number

$32,81
60% OFF
$13,13

20% OFF EXTRA automáticamente al pagar con Deuna

Envío gratis
Llega en 26 o más días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja de USA a tus manos en
Medios de pago Tarjetas de Débito, Crédito y Deuna

Compra protegida

Disfruta de una experiencia de compra segura y confiable

Conoce más detalles

Technical Specifications: Voltage Supply: 9-12V DC Input Waveforms: Square, Sine & Triangle Impedance: 600 Ohm + 10% Frequency: 1Hz - 1MHz SINE WAVE Amplitude: 0 - 3V at 9V DC input Distortion: Less than 1% (at 1kHz) ? Flatness: +0.05dB 1Hz - 100kHz SQUARE WAVE Amplitude: 8V (no load) at 9V DC input Rise Time: Less than 50ns (at 1kHz) Fall Time: Less than 30ns (at 1kHz) Symmetry: Less than 5% (at 1kHz) TRIANGLE WAVE Amplitude: 0 - 3V at 9V DC input Linearity: Less than 1% (up to 100kHz) 10mA
