1800W 40A DC-DC 10-60V to 12-90V Step Up Boost Converter Current Power Supply Module +Fan

0 5 3 20

20 calificaciones

Disponibilidad
En stock

Peso con empaque
0.53 kg

Devolución
No

Condición
Nuevo

Producto de
Amazon

Sobre este producto

Specifications: Input voltage: DC 10V~60V,Output voltage: 12~90V adjustable,Input Current:10~30V input voltage, maximum current 30A,31~60V input voltage, maximum current 25A,Quiescent current: 15 mA ,Constant current range: 0.8-20A (+/- 0.3A).Output current: MAX 20A, if it exceeds 15A, please strengthen the heat dissipation.
[Protection Function]: 30A fuse, double short circuit protection, safer to use. 150A MOS meter input reverse connection protection, don't worry about input after burning out the power supply. Overcurrent protection, if the input exceeds 35A, there is a certain error range, and the output voltage will automatically decrease.
Do not use the short-circuit output current method. The short-circuit method cannot adjust the circuit structure of the boost module. When using the battery as the input source, the battery protection must be reduced, otherwise the battery and power supply will be damaged. The input power supply voltage must be above 10V, and the output polarity cannot be reversed or short-circuited.
[Widely Used]:Suitable for voltage regulation of solar panels, lithium batteries, rechargeable batteries, driving high-power LED lights, etc.
[Satisfactory Service]: We Provide 24-hour online service,If you encounter any problems, Please email SELLER SUPPORT (Not Amazon support), we will give you a perfect solution.

$42,76

31% OFF

$29,49
