Artículo: AMZ-B09J4L6DGM

Dorhea

3Pcs 3D Printer Inductive Proximity Sensor Switch LJ12A3-4-Z/BX 5V 300mA Detection NPN NO DC 6-36V 4mm Normally Open Proximity Switch LJ12A3-4-Z/BX-5V 4mm Detecting Distance 3 Wire

Size:

LJ12A3-4-Z/BX

LJ12A3-4-Z/AX

LJ12A3-4-Z/AY

LJ12A3-4-Z/BX

NJK-5002C

Disponibilidad
En stock
Peso con empaque
0.22 kg
Devolución
Condición
Nuevo
Producto de
Amazon

Sobre este producto
  • Inductive proximity switch LJ12A3-4-Z-BX wire type : 3 wire type (Black, Brown, Blue);Switch appearance type : Cylinder type; Operating Temperature : -25°C to +55°C (Non-freezing Condition);Size : 6.2 x 2cm/2.4'' x 0.8'' (L*Max. Dia);Cable Length : 110cm/43.3"
  • 3D printer inductive proximity sensor detection switch theory : Inductive sensor; Output type : NPN NO(Normal Open); Thread diameter : 12mm/0.5"""" ; Head diameter : 11.8mm/0.46"""";Detecting distance : 4mm; Supply voltage : DC 6-36V; Current output : 300mA; Response frequency : 150Hz
  • LJ12A3-4-Z/BX is a component widely used for detecting, controlling and non-contact switching.
  • A control signal is sent out when the proximity switch is close to a target object. The red LED indicates the sensor operating status.
  • LJ12A3-4-Z/BX-5V object detecting target is not limited to conductors, also used for liquids and powders, Polarity reversal protection, short circuit protection. Operating voltage from 6V up to 36V DC.
$43,76
60% OFF
$17,51

IMPORT EASILY

By purchasing this product you can deduct VAT with your RUT number

$43,76
60% OFF
$17,51

Difiere a 3 y 6 meses sin intereses con Diners, Discover y Titanium

Envío gratis
Llega en 5 a 12 días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja de USA a tus manos en
Medios de pago Tarjetas de Débito, Crédito y Deuna

Compra protegida

Disfruta de una experiencia de compra segura y confiable

Conoce más detalles

LJ12A3-4-Z-BX Inductive proximity switch Wire Type : 3 wire type (black, brown, blue) Switch Appearance Type : Cylinder type Operating Temperature : -25°C to +55°C (non-freezing condition) Size : 6.2 x 2cm/2.4'' x 0.8'' Cable Length : 110cm/43.3"""" switch theory : Inductive sensor Output type : NPN NO(Normal Open) Thread diameter : 12mm/0.5"""" Head diameter : 11.8mm/0.46"""" Detecting distance : 4mm Supply voltage : DC 6-36V Current output : 300mA Response frequency : 150Hz
