PT100 Simulator RTD PT100 Calibrator 0 to +500 Cel. Temperature Resistance Box for Platinum PT100 Calibration (Size : 0-500)
Size:
0-500
En stock
0.67 kg
No
Nuevo
Amazon
- Precision Portable PT100 Simulator RTD PT100 Calibrator 0 to +500 Cel. Temperature Range for Platinum PT100 Calibration for 2-wire 3-wire 4-wire PT100 signal Simulation
- PT100 Temperature Simulation Output 11 Fixed Temperature Points:
- 0℃, 50℃, 70℃, 100℃, 130℃, 150℃, 200℃, 250℃, 300℃, 400℃, 500℃.
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
Conoce más detalles
Precision Portable PT100 Simulator RTD PT100 Calibrator 0 to +500 Cel. Temperature Range for Platinum PT100 Calibration for 2-wire 3-wire 4-wire PT100 signal SimulationPT100 Temperature Simulation Output 11 Fixed Temperature Points:0℃, 50℃, 70℃, 100℃, 130℃, 150℃, 200℃, 250℃, 300℃, 400℃, 500℃.* Not continuous adjustable within 0 to +500℃ ., only switch among 11 temperature points.Operating Guides:Connect any 3 wires of PT100 simulator to the thermal resistance terminals of the temperature meter to be inspected. Then rotate the knob to one temperature value point. Next check the value displayed in the temperature meter is right or not. If the value displayed is right, the temperature meter inspected is normal, otherwise, it is not normal.Technical ParametersPrecision Portable PT100 Simulator Calibrator Package including1 Unit x Original PT100 RTD Simulator BRT ZY7-21 Set x Professional User manual (English)
