Artículo: AMZ-B0981CJPP5

Deeoee

2PCS Ultrasonic Module HC-SR04 Distance Measuring Transducer Sensor for Arduino HCSR04 DC 5V IO Trigger Sensor Module HC SR04

Disponibilidad
En stock
Peso con empaque
0.43 kg
Devolución
Condición
Nuevo
Producto de
Amazon

Sobre este producto
  • 2PCS Ultrasonic Module HC-SR04 Distance Measuring Transducer Sensor for Arduino HCSR04 DC 5V IO Trigger Sensor Module HC SR04
$19,93
31% OFF
$13,75

IMPORT EASILY

By purchasing this product you can deduct VAT with your RUT number

$19,93
31% OFF
$13,75

Difiere a 3 y 6 meses sin intereses con Diners, Discover y Titanium

Envío gratis
Llega en 12 a 16 días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja de USA a tus manos en
Medios de pago Tarjetas de Débito, Crédito y Deuna

Compra protegida

Disfruta de una experiencia de compra segura y confiable

Conoce más detalles

1.This module performance is stable, measure the distance accurately. performance nearly the same as SRF05, SRF02 SRF05, SRF02 ultrasonic distance measuring module and other comparable. Module High precision, blind spots (2cm) super close. 2.Main technical parameters: Voltage: DC 5V Static current: less than 2mA Electrical level output: 5V high Electrical level output: at the end of 0V Induction angle: not more than 15 degrees Detection distance: 2cm-450cm High precision: 2mm Wiring: VCC, trig (control side), echo (receiving end), GND 3.Module works: using IO trigger distance, the high signal to at least 10us module automatically sends eight 40khz square wave, automatically detects whether a signal return; a signal back, through the IO output a high electrical level, high electrical level duration is: the ultrasound time from launch to return. Test distance = (time of the high electrical level * speed of sound (340M / S)) / 2;
