Waveshare
Mini Base Board for Raspberry Pi Compute Module 4 Lite/EMMC Series Module, with Standard CM4 Socket and Color-Coded Raspberry Pi 40PIN GPIO Header, for Evaluating CM4 or Integrated into End Product
Color:
CM4-IO-BASE-A
Disponibilidad
En stock
En stock
Peso con empaque
0.20 kg
0.20 kg
Devolución
Sí
Sí
Condición
Nuevo
Nuevo
Producto de
Amazon
Amazon
Sobre este producto
- Mini base board designed for Raspberry Pi Compute Module 4, suitable for evaluating the raspberry pi CM4 or being integrated into end products
- Compared with version B, there're NO RTC, Fan controller, and battery holder on version A, which is more cost effective
- Standard Raspberry Pi CM4 socket and color-coded Raspberry Pi 40PIN GPIO header, suitable for Compute Module 4 Lite/EMMC series module
- Onboard multiple connectors including: CSI/DSI/FAN/HDMI/USB/RJ45 Gigabit Ethernet/Micro SD Card Slot/M.2 Slot
- Comes with mounting screw, easy to install. When using the M.2 interface, please use the matching screws.
$67,23
44% OFF
$37,35
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
$67,23
44% OFF
$37,35
Difiere a 3 y 6 meses sin intereses con Diners, Discover y Titanium
Envío gratis
Llega en 5 a 12 días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Compra protegida
Disfruta de una experiencia de compra segura y confiable
![]()
Garantía de entrega
Con Tiendamia todas tus compras cuentan con Garantía de Entrega o devolución total de tu dinero.
Compras 100% seguras y garantizadas, para que pidas lo que sueñas y lo recibas del mundo a tu puerta.
Tarjetas de Débito y Crédito
Visa
Mastercard
American Express
Dinners
Discover
Alias
Pagos a través de PayPal
Compra procesada en dólares con dinero en cuenta o tarjetas internacionales.
PayPal
Conoce más detalles
Introduction CM4-IO-BASE-A is an IO board designed for Raspberry Pi Compute Module 4, it can be used with all versions of CM4, suitable for evaluating the Raspberry Pi CM4 or beingintegrated into end products. Precautions for Use 1: It is forbidden to unplug and plug any equipment other than USB and HDMI when power is on 2: FAN fans only support 5V fans. 12V is not supported. Confirm the fan voltage before connecting. This version of the fan does not have a controller and cannot be adjusted in speed. 3: The DSI display interface is the DSI0 interface, and the DSI1 display interface is not connected. 4: Type C interface can be used for power supply or USB SLAVE interface for burning image. 5: In order to ensure the normal power supply of CM4, please do not connect other devices when using the Type C interface to burn the image. 6: When CM4 is in normal use, it needs to provide 5V 2A power supply for CM4. Otherwise, problems such as automatic shutdown, frequency reduction, etc. may occur. 7: When using the M.2 interface, please use the matching screws. Using screws of other lengths may cause the CM4 core to be damaged by the screws. 8: The module does not have any protection, please do not short-circuit the power supply. 9: USB2.0 is closed by default, if you need to open it, you need to add dtoverlay=dwc2,dr_mode=host 10: If you want to use HDMI1 alone, you can purchase it separately if you need to use it HDMI Adapter 11: Both USB 3/4 and HDMI1 need to be used, you can use adapter board to connect it out 12: This expansion board does not support the POE function. 13: M.2 interface power supply is limited to 1.5A, if it causes problems such as slowing down of solid state or other equipment, it is recommended to buy version B Package Content 1. CM4-IO-BASE-A x1 2. Mounting screw x1
