Signswise Incremental Optical Rotary Encoder for Arduino 600P/R Wide Voltage Power Supply DC 5-24V 6mm Shaft Quadrature
Disponibilidad
En stock
En stock
Peso con empaque
0.22 kg
0.22 kg
Devolución
Sí
Sí
Condición
Nuevo
Nuevo
Producto de
Amazon
Amazon
Sobre este producto
- Precise Measurement: Accurately tracks rotational speed, angle, and acceleration for various applications
- Versatile Connection: Compatible with Arduino and other systems, featuring AB 2-phase output and NPN open collector output
- Wide Voltage Range: Operates smoothly with DC power supply from 5 to 24 volts
- Durable Construction: Robust design with a 6mm shaft and high axis stopper platform, suitable for demanding environments
- Easy Integration: Compact size (38 x 35.5mm) and clear color-coded connections for simple installation
$36,90
31% OFF
$25,45
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
$36,90
31% OFF
$25,45
2 meses de gracia en diferidos con Banco Guayaquil
Compra más de $100 y te regalamos la mitad de la tasa arancelaria
Envío gratis
Llega en 5 a 12 días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Compra protegida
Disfruta de una experiencia de compra segura y confiable
![]()
Garantía de entrega
Con Tiendamia todas tus compras cuentan con Garantía de Entrega o devolución total de tu dinero.
Compras 100% seguras y garantizadas, para que pidas lo que sueñas y lo recibas del mundo a tu puerta.
Tarjetas de Débito y Crédito
Visa
Mastercard
American Express
Dinners
Discover
Alias
Pagos a través de PayPal
Compra procesada en dólares con dinero en cuenta o tarjetas internacionales.
PayPal
Conoce más detalles
Functions √ This incremental optical rotary encoder can be used to measure the rotational speed, angle and acceleration of the object and the length measurement. √ This shaft encoder is suitable for a variety of intelligent control displacement measurement, automatic fixed- length automatic guillotine paper machine, steel cut length control, civilian measured height human scale, students racing robots. Connection: Yellow = A phase, Blue = B phase, Red =Vcc power +, Black = V0 Notice: AB 2phase output must not be directly connected with VCC, otherwise, it will burn the output triode. Specification 360 p/r (Single-phase 360 pulses/R,Two phase 4 frequency doubling to 1440 pulses). -Encoder size: 38 x 35.5mm/1.49" x 1.39" -Shaft: 6 x 13mm/0.23" x 0.51" -Axis stopper platform: High 5mm, 20mm -Power source: DC 5-24V -Maximum mechanical speed: 5000 R / min -Response frequency: 0-20KHz Output: AB 2phase output rectangular orthogonal pulse circuit, the output for the NPN open collector output type Package content 1 x 360P/R Incremental Rotary Encoder
