110V 63A 2P Dual Power Automatic Transfer Switch, Dual Power Generator Changeover Switch, Automatic & Manual Conversion Options, ATS, 50/60HZ AC-33iB
En stock
1.29 kg
Sí
Nuevo
Amazon
USA
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
Conoce más detalles
【Product Specifications】Line voltage: AC 110V, line current: 6A-63A, operating frequency: 50Hz/60Hz, conversion time: 2 seconds or so, installation dimensions: 5.04in x 4.8in (128mm x 122mm), mounting hole diameter: M6 【Automatic & Manual Modes】 This dual power automatic transfer switch offers two operating modes: automatic and manual button. It features simple operation and reliable performance. When a power source fails (by detecting only the loss of voltage or phase failure in the main A-phase and backup A-phase), it automatically transfers one or more load circuits from the faulty source to the alternative source, ensuring continuous power supply to the load circuits 【Function】This 110v 36a 2p switch incorporates multiple protection functions, including short circuit, overload, phase loss, under voltage, and loss of voltage protection 【Easy to Install】This dual power automatic transfer switch is constructed with high quality materials, easy installation (includes instruction Manual). For safety and reliability, it is recommended that all main and backup circuits be connected through a circuit breaker. 【Application】This automatic transfer switch is suitable for residential, hospital, and Important office premises, with particular applicability in office buildings and public spaces requiring fire protection systems to ensure uninterrupted power supply
