SKU/Artículo: AMZ-B0FMFT1M9X
Teyleten Robot
Teyleten Robot AD7606 Module Multi-Channel AD Data Acquisition Module 16-bit ADC 8-Channel Synchronization Sampling Frequency 200KHz
Detalles del producto
Disponibilidad:
En stock
En stock
Peso con empaque:
0.15 kg
0.15 kg
Devolución:
Sí
Sí
Condición
Nuevo
Nuevo
Producto de:
Amazon
Amazon
Viaja desde
USA
USA
Sobre este producto
- Product Overview Features a 3.81 industrial-grade PCB connector for enhanced stability and reliability. Supports simultaneous 8-channel data acquisition at 200 kHz. Data interfaces include SPI or 16-bit parallel port, with user-selectable options. Utilizes imported, brand-new, genuine chips for guaranteed quality. The AD7606 is a 16-bit, 8-channel synchronous sampling analog-to-digital data acquisition chip with a sampling rate of up to 200 kSPS per channel. It features built-in analog input clamping protection, a second-order anti-aliasing filter, a tracking hold amplifier, a 16-bit charge redistribution successive approximation ADC, a digital filter, a 2.5V reference voltage source, a reference voltage buffer, and high-speed serial and parallel interfaces. It operates on a single 5V power supply, features on-chip filtering, and has high input impedance, eliminating the need for driver operational amplifiers and external bipolar power supplies. The anti-aliasing filter has a 3dB cutoff frequency of 22 kHz; at a sampling rate of 200 kSPS, it provides 40 dB anti-aliasing suppression. The input clamping protection circuit ensures the input can withstand voltages up to ±16.5V. It can be applied in systems such as power line monitoring and protection, multi-phase motor control, instrumentation and control, multi-axis positioning, and data acquisition. Module usage precautions (1) The module is a low-power module; the supply voltage must not exceed 5.5V, and the signal input voltage must not exceed ±16.5V. (2) Since the module is a high-precision device, it is recommended to use a linear power supply to avoid unnecessary interference. (3) The output signal lines should be kept as short as possible, as longer lines may introduce noise signals. Poor contact or low-quality wiring may cause signal attenuation or excessive noise.
AR$81.185
49% OFF
AR$41.634
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
AR$81.185
49% OFF
AR$41.634
Pagá fácil y rápido con Mercado Pago o MODO
Llega en 8 a 12 días hábiles
con envío
Tienes garantía de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Conoce más detalles
Module power supply: DC 5V; Module current: 20mA (MAX) Module communication protocol: SPI serial, 8-channel data parallel; Module control signal level: 3.3V Module input voltage range: ±5V or ±10V; input impedance: 1MΩ ADC resolution: 16 bits; sampling rate: 200KSPS Number of input channels: 8 independent channels; module input interface: 3.81–8-pin connector Reference voltage: internal 2.5V; oversampling modes: 6; output mode: 8-channel data serial or parallel
