Consfly
Electronic Temperature Controller, 110V Digital Display Temperature Thermostat with Sensor, Freezer Temperature Controller with Defrosting Function, Equipped with External Transformer (SF-203)
Model:
SF-203
SF-102
SF-102S
SF-104P
SF-104S
SF-108
SF-201
SF-202
SF-203
SF-204
SF-574
Disponibilidad:
En stock
En stock
Peso con empaque:
0.53 kg
0.53 kg
Devolución:
No
No
Condición
Nuevo
Nuevo
Producto de:
Amazon
Amazon
Sobre este producto
- 【What Will You Receive】The digital temperature controller package includes an external transformer, two temperature sensors, a set of mounting brackets, a set of baffles, and an English instruction manual.
- 【How to choose a suitable controller】Determine the digital temperature controller size and freezer opening size, and determine whether the relevant parameters of the 110v thermostat meet the requirements, such as temperature control, product functionality, etc.
- 【Note】The thermostat cannot be installed in areas with dripping water. When installing the probe, the head should be facing downwards and the line should be facing downwards. The defrosting probe should be placed in the thickest frozen area of the evaporator metal sheet and should not be close to the heating wire.
- 【Multifunctional Temperature Controller】The functions of this SF-104 temperature controller include temperature display, temperature control, manual and automatic electric defrosting, evaporator fan control, time temperature termination defrosting, setting memory, parameter locking, and self diagnosis.
- 【Widely Application】Suitable for refrigerators, display cabinets, and cold storage.
AR$512,386
49% OFF
AR$262,760
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
AR$512,386
49% OFF
AR$262,760
Pagá fácil y rápido con Mercado Pago o MODO
Llega en 18 a 28 días hábiles
con envío
Tienes garantía de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Compra protegida
Disfruta de una experiencia de compra segura y confiable
Tarjetas de Crédito y Débito
Visa
Mastercard
American Express
Pagos a través de PayPal
Compra procesada en dólares con dinero en cuenta o tarjetas internacionales.
Paypal
Pagos a través de MODO
Compra procesada en pesos desde la App de tu banco.
PayPal
Conoce más detalles
Functional Characteristics: 1、Small integrated intelligent control, capable of directly controlling compressors up to one horsepower；2、Temperature Display /Temperature Control /Shutdown Defrosting /High and Low Temperature Alarms /Lighting Control /Defogging Control /Set Memory /Parameter Locking /Self Diagnosis Parameter Information 1. External sealed transformer output: AC 12V (each transformer can only be used with one temperature controller)2..Temperature sensing probe: NTC, one piece, 2 meters long (regardless of positive or negative)3. Temperature display range: -45~150° C ;Accuracy: ± 1 ° C (± 2 ° F)4. Control temperature range: -45 ° C to 50 ° C (-49 ° F to 122° F)5. Appearance size: 142mm (length) × 40mm (width) × 40mm (deep) Opening size: 138mm (length) × 32.5mm (width)6. Working environment temperature: -10~60 ° C (14~140 ° F); Relative humidity: 20% to 90% (without condensation)7.Relay contact capacity:Compressor: Normally open 30A/250VAC (can be directly used for one compressor, if exceeded, an AC contactor should be connected);Lighting Relay: normally open 5A/250VAC; Glass Defogging Relay: normally open 10A/250VAC Temperature Controller Accessories: 1. One external transformer; 2. One temperature sensing probe; 3. A set of installation brackets;
