SKU/Artículo: AMZ-B0C6H546Z9
Fafeicy
36V Relay Module, 8-36V Relay Module 4-Channel Multifunction Time Delay Relay Interface Board Module Optocoupler LED, Voltage Monitoring Relays
Detalles del producto
Disponibilidad:
En stock
En stock
Peso con empaque:
0.15 kg
0.15 kg
Devolución:
No
No
Condición
Nuevo
Nuevo
Producto de:
Amazon
Amazon
Viaja desde
USA
USA
Sobre este producto
- Electric Parameter: Working voltage: recommended DC 8v-36v (extreme working voltage DC 6v-45v) Rated power: Static power less than 0.1W Dynamic power is less than 1.5W Working temperature: recommended - 20 ℃ to 60 ℃ (limit working temperature range - 30 ℃-70 ℃) Load capacity: Normally open port: DC 0-30V /10A, AC 0-250V /10A Normally closed port: DC 0-28V /10A, AC 0-125V /10A Module Port: Module voltage/ input terminal: there are 8 line interfaces, all of which have terminals for user convenience VIN: DC positive pole GND: DC negative pole OFF: Power control terminal COM: Pommon end of photoelectric isolation input IN1-IN4: Input detection interface Relay load output: 12 - wire interface, all interfaces have terminals Note: The input detection interface can be either active-high or active-low. The user can select via COM port. If COM is connected to H, IN1-IN4 is active high, if COM is connected to L, IN1 -IN4 is active low! Specifications: Material: ABS Size: Approx. 85 x 75mm / 3.35 x 2.95in Weight: Approx. 88g Package List: 1 x Relay Module
AR$64.818
49% OFF
AR$33.240
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
AR$64.818
49% OFF
AR$33.240
Pagá fácil y rápido con Mercado Pago o MODO
Llega en 18 a 28 días hábiles
con envío
Tienes garantía de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Conoce más detalles
The time delay relay module presets up to 20 functions, adopts 8-36V wide voltage power supply design, and adds the linkage function of each channel. Users can freely combine many new applications, such as sequential linkage and cyclic linkage. The module presets up to 20 functions, adopts 8-36V wide voltage power supply design, and increases the linkage function of each channel. Users can freely combine various new applications, such as sequential linkage and cyclic linkage. HIGH :At least 1 second timing function can be set, accurate timing, error less than 1% Number of channels: The relay module has 4 channels of input and output control, and each channel can be set with 20 functions to meet more application requirements. DC 8v-36v wide voltage input with power supply anti-reverse function, will not damage the module due to power connection error.
