SKU/Artículo: AMZ-B0BPLQ1JM3
ATO
ATO 10hp Three Phase Input Output VFD 480V, 3 Phase VFD 7.5kW 17A Variable Frequency Drive Inverter (480)
Voltage:
480.0 Volts
Detalles del producto
Disponibilidad:
En stock
En stock
Peso con empaque:
4.69 kg
4.69 kg
Devolución:
Sí
Sí
Condición
Nuevo
Nuevo
Producto de:
Amazon
Amazon
Viaja desde
USA
USA
Sobre este producto
- ATO 10 hp 7.5 kW VFD Inverter Converter, three phase 220V/440V/480V input for option, three phase output variable frequency drive, 17 amps, V/F & vector control, IP20 enclosure. ATO 3 phase input output VFD Specification:Basics:Capacity 10 hp (7.5 kW)Shipping weight 5 kgDimension 272*172*182 mmI/O Feature Rated current 17 AInput voltage 3 phase 220V /440V /480V AC ±15% (Optional)Input frequency 50Hz/ 60HzOutput voltage 3 phase AC 0~input voltageOutput frequency 0.00~400.00HzOver load capacity 150% of rated current for 1 minute, 180% of rated current for 3 secondsControl Feature Control mode V/F control;Sensorless vector control;Communication RS485Speed regulation 1:100Start torque 150% of rating torque at 1 HzSpeed control accuracy ≤±0.5% of rating synchronous speedFrequency precision Digital setting: max frequency x± 0.01%;Analog setting: max frequency x± 0.2%Frequency resolution Analog setting: 0.1% of max frequency;Digital setting: 0.01HzTorque boost Automatic torque boost, manual torque boost 0.1%~30.0%Interior PID controller Be convenient to make closed-loop systemAutomatic energy save running Optimize V/F curve automatically based on the load to realize power save runningAutomatic voltage regulation (AVR) Can keep constant output voltage when power source voltage varies.Automatic current limiting Limit running current automatically to avoid frequent over-current which will cause tripEnvironment Enclosure rating IP 20Temperature –10℃~ +40℃; VFD will be derated if ambient temperature exceed 40℃; each rise 1℃, the derate will be 5%Humidity 5%-95%, without condensationAltitude ≤1000m; VFD will be derated if above 1000mImpingement and oscillation Normal running:<5.9m/s2 (0.6g); Transpor
AR$2.187.439
60% OFF
AR$874.972
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
AR$2.187.439
60% OFF
AR$874.972
Llega en 8 a 12 días hábiles
con envío
Tienes garantía de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Conoce más detalles
【Input Parameters】10hp 7.5kW three phase VFD inverter , rated current: 17 A, Input voltage: 3 phase 480V AC ±15% (Optional), Input frequency: 50Hz/60Hz 【Output Parameters】10hp three phase output VFD variable frequency drive, Output voltage: 3 phase AC 0~input voltage, Output frequency: 0.00~400.00Hz 【Advantages】3 phase 480V VFD converter, with adjustable output frequency, automatic energy save running, automatic voltage regulation, limit running current automatically to avoid frequent over-current which will cause trip 【Wide Range of Applications】ATO 480V three phase input output VFD specialized designed for three phase induction motor, widely applied to control speed of the single phase motors, such as pumps, fans, power tools, etc. 【Package Includes】1* three phase VFD, 1*user manual
