SKU/Artículo: AMZ-B07V6XSCW2
CNCTOPBAOS
CNCTOPBAOS 4 Axis Offline Stand Alone CNC Motion Controller System DDCSV3.1,Servo/Stepper Motor Control Replace Mach3 PLC+100PPR MPG Handwheel with E-Stop for CNC Router Engraving Machine
Style:
Style-DDCSV-3
Detalles del producto
Disponibilidad:
En stock
En stock
Peso con empaque:
2.11 kg
2.11 kg
Devolución:
Sí
Sí
Condición
Nuevo
Nuevo
Producto de:
Amazon
Amazon
Viaja desde
USA
USA
Sobre este producto
- Parcel include:1 x 100PPR Pendant Handwheel mpg1 x 4 Axis CNC Offline Motion Controller DDCSV3.11 x 4GB USB Flash drive1 x USB Extension Cableuser manual will send via amazon email.Controller specification: Adopts the ARM+FPGA design framework. ARM controls the human-computer interface and code analysis and the FPGA provides the underlying algo rithms and creates the control pulse.The internal operating system is Linux based.Can be used for CNC machines. Lathes, Routers, Pick&Place and Mills etc.and operates as a Stand Alone system without the need of a computer.guarantees high precision,accuracy and reliability.Support the operation of quickly specify the running position;Support for “Power Cut” recovery. Data is automatically saved;Only support NPN type limited switchThe main control equipment is 24V power input, the current capacity is required not to be lower than 0.5A;Support the USB flash disk to read the G code,and the size of G codefile has no requirement;mode”;3 kinds Probing Modes:Fixed Position of tool sensor,Floating Position of the tool sensor,Rectangular block Sensor;Enhenced the software,added a lot of parameters,Optimal Design and Algorithm,makes Handwheel specification:CNC system and position control of various mechanical devicesMetal code disc, high precision, good textureResolution:100PPRSupply Voltage:DC5V +/-5%Supply Current:≤80mAOutput Voltage:≥2.5V and ≤0.4VOutput Current:<40mAFall/Rise time:≤5ns(typ)Switch:X1,X10,X100Axis Switch:OFF,X,Y,Z,4Response Frequency:0-10KHz
AR$1.044.509
49% OFF
AR$535.650
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
AR$1.044.509
49% OFF
AR$535.650
Pagá fácil y rápido con Mercado Pago o MODO
Llega en 8 a 12 días hábiles
con envío
Tienes garantía de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Conoce más detalles
Brief introduction: The DDCSV3.1 is a 4 axis motion controller,the highest output pulse per axis is 500KHz;This provides high control precision for stepper motors and servo motors;The DDCS operates as a stand alone system without the need of a computer,and it needs two 24V DC power supplies Specifications: 5 inches TFT Screen; Resolution ratio: 480x272; The highest output pulse per axis is 500KHz,this provides high control precision for stepper motors and servo motors; All operations are controlled by only 17 keys and it supports the FANUC with high universality to be compatible with G code set,with 4G USB flash disk support for G code file input,no size limited of the G-code file Brief technical features: 16 photoelectric isolated digital inputs,3 photoelectric isolated digital outputs; Analog spindle control 0-10V spindle control,can be modified as PWM output; ARM9 main control chip,FPGA core algorithm chip ;Jog function for each axis,continuous, step, defined distance; Customer can define the distance; Support NPN type limited switch 4 Axis MPG Handwheel: Resolution:100 PPR ; X,Y,Z,4th axis selector switch ; Switch:x1,x10,x100,with Emergency stop and LED indicator; This MPG comes with a 15-pin plug, which can be directly connected to the 15-pin socket of the controller MPG Applications: The DDCV3.1 controller can be used for many styles and types of CNC machines, Lathes, CNC Router, Milling Machine,Engraving Machine and Cutters are just a few examples
