IR Infrared Obstacle Avoidance Sensor (2pcs) IR Transmitting and Receiving Tube Photoelectric Switch 3-pin Compatible with Ar-duino Smart Car Robot
Number of Items:
2
Disponibilidad:
En stock
En stock
Peso con empaque:
0.33 kg
0.33 kg
Devolución:
Sí
Sí
Condición
Nuevo
Nuevo
Producto de:
Amazon
Amazon
Sobre este producto
- ☆The sensor module has strong ability to adapt to ambient light. It has a pair of infrared transmitting and receiving tubes. The transmitting tube emits infrared light of a certain frequency.
- ☆Signal output interface outputs a digital signal (a low-level signal). The detection distance can be adjusted by the potentiometer knob. The effective range is 2 to 30cm and the working voltage is 3.3V.5V.
- ☆The sensor's detection distance can be adjusted by a potentiometer, has small interference, is easy to assemble, and is easy to use.
- ☆It can be widely used in robots to avoid obstacles, avoid cars, count pipelines, and track black and white lines.
- ☆Sensor module output port OUT can be directly connected with the microcontroller IO port can also directly drive a 5V relay; connection mode: VCC-VCC; GND-GND; OUT-IO.
AR$25,087
31% OFF
AR$17,296
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
AR$25,087
31% OFF
AR$17,296
Pagá fácil y rápido con Mercado Pago o MODO
Llega en 8 a 12 días hábiles
con envío
Tienes garantía de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Compra protegida
Disfruta de una experiencia de compra segura y confiable
Tarjetas de Crédito y Débito
Visa
Mastercard
American Express
Pagos a través de PayPal
Compra procesada en dólares con dinero en cuenta o tarjetas internacionales.
Paypal
Pagos a través de MODO
Compra procesada en pesos desde la App de tu banco.
PayPal
Conoce más detalles
1. When the module detects an obstacle in front of the signal , the green indicator light on the board level , while low-level continuous output signal OUT port , the module detects the distance 2 ~ 30cm, detection angle 35 °, the distance can detect potential is adjusted clockwise adjustment potentiometer to detect the distance increases ; counterclockwise to adjust the potentiometer to reduce the detection distance . 2 .active infrared sensors to detect the reflected , and thus the shape of the reflectivity of the target detection range is critical . The minimum detection distance which black , white maximum ; small objects from a small area , a large area from the Grand . 3 . the output port OUT sensor module can be directly connected to the microcontroller IO port , you can directly drive a 5V relay ; Connection : VCC-VCC; GND-GND; OUT-IO 4 .using the comparator LM393, stable ; 5 .can be used for 3-5V DC power supply modules . When the power is turned on, the red power. Package Included: 2 x Smart car Obstacle avoidance Infrared Sensor module.
