CPU 224XP Ethernet Industrial Control Board Digital Input Output Programmable Logic Controller with Analog Quantity(CPU224XP MT 24V)
Color:
CPU224XP MT 24V
En stock
0.20 kg
No
Nuevo
Amazon
USA
- Modules Features: 1.Compatible with s7-200 programming software. 2.Compatible with s7-200 instruction set.(it does not support MAP libraries and PTO wizards, but it can support text wizards, PID wizards, PWM wizards, and high counter wizards) 3.Compatible with V4.0 STEP 7 MicroWIN SP4 and above versions. 4.It comes with 14 digital inputs, 10 digital outputs, 2 analog inputs, and 1 analog output. 5.6-way high-speed counter, bidirectional input. 6.2 high-speed pulse outputs, each 100KHZ, 10A current. 7.AD input, with two 10 bit inputs of 0V~10V. 8.DA output, 1 channel of 10 bit output, 0-32767 corresponding to 0-10V. 9.Communication port, supporting dual independent PPI, and the communication Baud is 9.6K, 19.2K, 187.5K; Supports free port, MODBUS library, and USS library. 9.Supports PID wizard and 8-way PID control. 10. Level 4 encryption, unbreakable after it encrypted, fully protecting your program! 11.Equipped with an expansion port. ========== Type : DC/DC Converters
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
Conoce más detalles
Modules CPU 224XP Ethernet Industrial Control Board Digital Input Output Programmable Logic Controller With Analog Quantity
