hiBCTR 250W DC-DC Boost Converter Module - Adjustable 10-40V to 10-50V 6A Output with Constant Voltage Current CC CV Power Supply for LED Driver/Solar/DIY
En stock
0.20 kg
Sí
Nuevo
Amazon
USA
- Description: Module properties: non-isolated step-up module (BOOST) Input voltage: DC10V-40V Input current: 6A (MAX) exceeds4A please enhance heat dissipation Quiescent current: 10mA (12V liter 20V, the output voltage, the higher the current will increase too quiet) Output voltage: 10-50V continuously adjustable Constant range: 0.2-6A Temperature: -40 to + 85 degrees (ambient temperature is too high, please enhance heat dissipation) Operating frequency: 150KHz Conversion efficiency: up to 96% Overcurrent protection: There Input reverse polarity protection: Yes, Installation: 4 3mm screw holes Connection method: Connection Output Module size: Length 70mm width 36mm height 13mm Single module: 50g Applications: 1, DIY a power supply, 12V can input and output can 12-50V adjustable. 2, the power supply for your electronic device, according to your system can set the output voltage value. 3, as the car power supply for your laptop, PDA or a variety of digital products supply. 4, DIY a mobile notebook power supply: 12V coupled with high-capacity lithium battery pack, so you can go where light where books. 5, solar panel regulator. 6, To the battery, rechargeable lithium batteries. 7, driving high-power LED lights.
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
Conoce más detalles
Module Name:Boost Constant Current Mobile Power Module Feature:Non - isolated boost module (BOOST) Input Voltage:DC 10V - 40V Output Voltage:10 - 50V continuously adjustable Operating Frequency:150kHz
