Artículo: AMZ-B0FNR6P7VS

Denash

Denash EVSE Test Adapter, 4mm Plug Compatibility Tester, EV Charging Station Tester with Type 2 Plug & LED Indicators Compatible with Testers, Multimeters

Detalles del producto
Disponibilidad
En stock
Peso con empaque
1.79 kg
Devolución
Condición
Nuevo
Producto de
Amazon
Viaja desde
USA

Sobre este producto
  • 1. EVSE Tester Kit: Simulate the presence of electric vehicles and equipped with European standard Type 2 plug for easy testing of European standard AC electric vehicle charging stations. 2. Voltage Tester: Take over and simulate communication between charging stations and electric vehicles. Connects to installation testers or multimeters. 3. Universal 4mm Socket: Compatible with testers, multimeters, and oscilloscopes for checking load voltage and CP signal output. 4. LED Indicator: Built-in LED lights indicate the presence of phases. Each phase can be individually checked. 5. Rotating Switches: PP switch simulates different charging cables - Open, 13A, 20A, 32A, 63A. CP switch helps simulate common vehicle states - A, B, C, D. Specification: Item Type: Electric Vehicle Charging Station Test Adapter Frequency: 50/60Hz Current: 10A Type 2 Testing Cable: AC Charging Mode 3, suitable for IEC62196-2 Type 2 socket or fixed cable with vehicle connector (Type 2, 7 pole, three-phase) Measurement Category: IEC/EN 61851-1/IEC/HD, 60364-7-722, 600VCATII Protection Grade: IP54 Package List: 1 * Tester 1 * EVA Case 1 * User Manual
$689,04
31% OFF
$475,20

Producto no disponible

Este producto no está permitido por la aduana del país en categoria 4x4

Este producto viaja de USA a tus manos en

Conoce más detalles

EVSE Tester Kit: Simulate the presence of electric vehicles and equipped with European standard Type 2 plug for easy testing of European standard AC electric vehicle charging stations. Voltage Tester: Take over and simulate communication between charging stations and electric vehicles. Connects to installation testers or multimeters. Universal 4mm Socket: Compatible with testers, multimeters, and oscilloscopes for checking load voltage and CP signal output. LED Indicator: Built-in LED lights indicate the presence of phases. Each phase can be individually checked. Rotating Switches: PP switch simulates different charging cables - Open, 13A, 20A, 32A, 63A. CP switch helps simulate common vehicle states - A, B, C, D.
