Artículo: AMZ-B0FCFT1P5X

Ransanx

20 Pack A3144 Hall Effect Sensor 3Pins Magnetic Detector for Arduino DC 4V-24V Hall Effect

Size:

20pcs

6pcs

Style:

20pcs

6pcs hall effect sensor hall effect hall sensor contact sensor

Detalles del producto

Disponibilidad
En stock

Peso con empaque
0.20 kg

Devolución
Sí

Condición
Nuevo

Producto de
Amazon

Viaja desde
USA

Sobre este producto

Product description：A3144E Hall element 44E OH44E Hall sensor Hall switch integrated circuit applies the principle of Hall effect and adopts semiconductor integration technology to manufacture a magnetic sensitive circuit. It is a magnetic sensing circuit composed of a voltage regulator, a Hall voltage generator, a differential amplifier, a Schmidt flip-flop, a temperature compensation circuit and an output stage with an open collector. Its input is the magnetic induction intensity and the output is a digital voltage signal Limit parameter：(25 ℃) Power supply voltage VCC: 24V Output reverse breakdown voltage VCE: 50V Output low current IOL: 50mA Working environment temperature Ta: E file: -20~ 85 ℃, L file: -40~ 150 ℃ Storage temperature range Ts: -65~ 150 ℃ Product features：Small size, high sensitivity, fast response, good temperature performance, high precision, high reliability Typical application：No touchpoint switch, automobile igniter, brake circuit, position, speed detection and control, safety alarm device, textile control system

$15,21

31% OFF

$10,49

$15,21

31% OFF

$10,49

Envío gratis

Llega en 5 a 12 días hábiles

Con envío

Tienes garantia de entrega

Medios de pago

Cantidad

Este producto viaja de USA

a tus manos en

Medios de pago

Conoce más detalles

Hall effect sensor parameters: power supply voltage: Vcc 4~ 24V; output reverse breakdown voltage: Vce 50V; color: black Hall effect temperature range: -40 ℃~ 125 ℃; storage temperature range: -55~ 150 ℃ Advantages: small size, high sensitivity, fast response, good temperature performance, high precision and high reliability. Widely used: non-contact switches, automatic ignition, braking circuits, position, speed detection and control, safety alarm devices, textile control systems, brushless DC motors, encoders, sewing equipment, textile machinery, household appliances, safety alarm devices and other automation control fields. Packing list: You will receive 20 PCS Hall effect switches; if you have any questions, please contact us, we are online 24 hours a day, and we will solve it for you as soon as possible.
