Artículo: AMZ-B0FC67MKXS

TUOPUONE

PCIe to M.2 Adapter with PoE Function (C) for Raspbery Pi 5, Supports NVMe Protocol M.2 Solid State Drive, High-Speed Reading/Writing (PoE M.2 HAT+ (C))

Detalles del producto

Disponibilidad
En stock

Peso con empaque
0.20 kg

Devolución
No

Condición
Nuevo

Producto de
Amazon

Viaja desde
USA

Sobre este producto

Introduction The POE M.2 HAT+ is an expansion board for Raspbery Pi 5 that combines two functions: Ethernet Power Supply (PoE) and PCIE to M.2 conversion, supporting the IEEE 802.3af/at network standard. It supports M.2 NVMe hard drives in 2230 and 2242 sizes, and supports SSD boot for the Raspbery Pi. Features ● Standard Raspbery Pi 40pin GPIO extension header, supports Raspbery Pi 5 (not applicable to PI4B and PI3B). ● Supports Power over Ethernet (PoE), supports IEEE 802.3af/at PoE network standard. ● Adopts fully isolated Switch Mode Power Supply (SMPS) mode power. ● Supports NVMe protocol M.2 interface hard drives, featuring high-speed read and write, and high work efficiency. ● PCI-E×1 Gen2 or Gen3 mode. ● Only supports PI5B. ● Compatible with M.2 hard drives of 2230 / 2242 sizes. ● Onboard operational indicator lights, the PWR is continuously lit when powered on, and the ACT blinks during read and write operations, making the operational status easily visible. ● POE planar transformer. Specifications PoE Power Input: 37V ~ 57V DC in Power Output: GPIO header: 5V 5A (MAX) Dimensions: 56.5 × 66.0 (mm) Network Standard: IEEE 802.3af/at PoE Package Content 1. PoE M.2 HAT+ (C) × 1 2. 2*2PIN header × 1 3. 2*20PIN header × 1 4. Screws pack × 1 5. SSD mounting screw × 1

$118,93

60% OFF

$47,57

$118,93

60% OFF

$47,57

Envío gratis

Llega en 26 o más días hábiles

Tienes garantia de entrega

Medios de pago

Cantidad

Este producto viaja de USA

a tus manos en

Medios de pago

Conoce más detalles

Standard Raspbery Pi 40pin GPIO extension header, supports Raspbery Pi 5 (not applicable to PI4B and PI3B). Supports Power over Ethernet (PoE), supports IEEE 802.3af/at PoE network standard. Adopts fully isolated Switch Mode Power Supply (SMPS) mode power. Supports NVMe protocol M.2 interface hard drives, featuring high-speed read and write, and high work efficiency. PCI-E×1 Gen2 or Gen3 mode. Only supports PI5B. Compatible with M.2 hard drives of 2230 / 2242 sizes. Onboard operational indicator lights, the PWR is continuously lit when powered on, and the ACT blinks during read and write operations, making the operational status easily visible. POE planar transformer.
