MakerFocus ESP32 LoRa V3 Development Board with 2000mAh Battery, Protective Case, 915MHz Antenna Integrated WiFi Bluetooth SX1262 CP2102 0.96-inch OLED Display Type C for Meshtastic IoT Arduino

Size:

With 2000mAh Battery and Case

With 2000mAh Battery Only

With 2000mAh Battery and Case

Detalles del producto

Disponibilidad
En stock

Peso con empaque
0.20 kg

Devolución
Sí

Condición
Nuevo

Producto de
Amazon

Viaja desde
USA

Sobre este producto

About WiFi LoRa: WiFi LoRa 32 (V3) is a classic IoT development board. It is the best option for smart cities, farms, homes, industrial control, house security, wireless meter reading and IoT developers Features: 1. Microprocessor: ESP32-S3FN8 (Frequency up to 240 MHz) 2. SX1262 LoRa node chip 3. With good RF circuit design and low-power design 4. Type-C USB interface with a complete voltage regulator, ESD protection, short circuit protection, RF shielding and other protection measures 5. Onboard SH1.25-2 battery interface, integrated lithium battery management system 6. Integrated WiFi, LoRa, Bluetooth three network connections, onboard Wi-Fi, Bluetooth dedicated 2.4GHz metal spring antenna, reserved IPEX (U.FL) interface for LoRa use 7. Onboard 0.96-inch 128*64 dot matrix OLED display can be used to display debugging information, battery power and other information 8. Integrated CP2102 USB to serial port chip, convenient for program downloading and debugging information printing 9. Support the Arduino development environment 10. We provide ESP32 + LoRaWAN protocol Arduino library, this is a standard LoRaWAN protocol that can communicate with any LoRa gateway running the LoRaWAN protocol Parameter: Max. TX Power: 21 ± 1 dBm Max. Receiving sensitivity: -139 dBm Wi-Fi: 802.11 b/g/n, up to 150Mbps Bluetooth: Bluetooth LE, Bluetooth 5, Bluetooth mesh Hardware Resource: 7*ADC1 + 2*ADC2; 7*Touch; 3*UART; 2*I2C; 2*SPI; etc. Memory: 384KB ROM; 512KB SRAM; 16KB RTC SRAM; 8MB SiP Flash Interface: Type-C USB; 2*1.25 lithium battery interface; LoRa ANT(IPEX1.0); 2*18*2.54 Header PinBattery: 3.7V lithium battery power supply and charging Operating temperature: -20 ~ 70 ℃ Dimensions: 50.2 * 25.5* 10.2 mm ----------------------------------------------------------------------- About 2000mAh Battery with Micro JST 1.25 Plug: Specification: Standard Voltage: 3.7V Capacity: 2000mAh Approx Weight : 35g Dimensions(±2mm): 50 * 33 * 10 mm /1.96 * 1.33 * 0.39inch(L*W*H) Discharge Rate: 1C Working Current: 1.5A The maximum discharging current: 3C Overcurrent Protection: 1.8-2.1A Type of Connector: Micro JST 1.25 Standard Charging Method: Charging this battery to 4.25V at 0.2C constant current, then charge the battery at a constant voltage of 4.2V till it's charging current ≦ 0.05C Note: 1. The maximum operating current of this battery is only about 1.5A, can not be used for unmanned aerial vehicles, model aircraft or power tools and other products that require high current 2. Connector is Micro JST 1.25 plug, it can be used for ESP32 ar duino development board whose plug is 1.25mm ----------------------------------------------------------------------- Package Content: 1 * WiFi LoRa 32(V3) 2 * Pin Headers 2 * Antenna 1 * Power Cord 1 * 2000mAh Battery with Micro JST 1.25 Plug 1 * Protective Shell

$111,17

60% OFF

$44,47

$111,17

60% OFF

$44,47

Envío gratis

Llega en 5 a 12 días hábiles

Con envío

Tienes garantia de entrega

Medios de pago

Cantidad

Este producto viaja de USA

a tus manos en

Medios de pago

Conoce más detalles

Support Arduino Development Environment: Support ESP32 + LoRaWAN protocol Arduino library, this is a standard LoRaWAN protocol that can communicate with any LoRa gateway running the LoRaWAN protocol Easy to Use: With good RF circuit design and low-power design, WiFi LoRa V3 is the best option for smart cities, farms, homes, industrial control, house security, wireless meter reading and IoT developers Highly Integrated: Integrated WiFi, LoRa, Bluetooth three network connections, onboard WiFi, Bluetooth dedicated 2.4GHz metal spring antenna, reserved IPEX (U.FL) interface for LoRa use. Integrated CP2102 USB to serial port chip, convenient for program downloading, debugging information printing Power Supply: Onboard SH1.25 battery interface, integrated lithium battery management system; you can also use the Type-C interface to power the development board OLED Display: Onboard 0.96-inch 128*64 dot matrix OLED display, which can be used to display debugging information, battery power and other information Note: Not all LoRa antennas fit the case. If the antenna protective shell is too long and cannot be installed into the shell, please shorten the antennas protective shell and be careful not to damage the internal copper tube
