Artículo: AMZ-B09MK2SBZ3

OONO

AC 100-240V 3Amp Blinking Flasher Module

Detalles del producto

Disponibilidad
En stock

Peso con empaque
0.20 kg

Devolución
Sí

Condición
Nuevo

Producto de
Amazon

Viaja desde
USA

Sobre este producto

FEATURES: This is a simple and practical blinking flasher module, the ON and OFF duration can be adjusted separately. The blinking flasher module is suited for resistive and inductive loads : lightbulbs, wirewound transformers for halogen lighting... (Note: the module no rectification, voltage step-up or step-down function, not suitable for DC lamps). Load on-off control uses solid-state device instead of electromagnetic relays, so there is no need to worry about the life of on-off times. Operating voltage AC 100 to 240V(47 to 63Hz). Maximum current: 3 Amp. Maximum load 350 Watts(at AC 115V), 700 Watts(at AC 230V). Time-ON 0.1 to 15 seconds and Time-OFF 0.1 to 15 seconds adjustable. The output ON - OFF - ON – OFF… cycle alternates. Two precise 25-turn adjustable potentiometers, you can use a screwdriver to easily adjust the ON and OFF time you need. With LED indication for output status. Compact plastic case and wires connects for easy mount. Two screw mounting holes are convenient for you to fix it on the wall or wooden board. Of course, you can also choose not to lock the screw. SPECIFICATIONS: AC power: 100 to 240VAC (47 to 63Hz). Maximum load: 350 Watts (115VAC), 700 Watts (230VAC). ON-time adjustable between: 0.1 to 15 seconds. OFF-time adjustable between: 0.1 to 15 seconds. No-load quiescent current: <1mA (115VAC), <2mA (230VAC).

$121,63

60% OFF

$48,65

$121,63

60% OFF

$48,65

Envío gratis

Llega en 5 a 12 días hábiles

Con envío

Tienes garantia de entrega

Medios de pago

Cantidad

Este producto viaja de USA

a tus manos en

Medios de pago

Conoce más detalles

This is a simple and practical blinking flasher module, the ON and OFF duration can be adjusted separately. The blinking flasher module is suited for resistive and inductive loads : lightbulbs, wirewound transformers for halogen lighting... (Note: the module no rectification, voltage step-up or step-down function, not suitable for DC lamps). Load on-off control uses solid-state device instead of electromagnetic relays, so there is no need to worry about the life of on-off times. Operating voltage AC 100 to 240V(47 to 63Hz). Maximum current: 3 Amp. Maximum load 350 Watts(at AC 115V), 700 Watts(at AC 230V). Time-ON 0.1 to 15 seconds and Time-OFF 0.1 to 15 seconds adjustable. The output ON - OFF - ON – OFF… cycle alternates. Two precise 25-turn adjustable potentiometers, you can use a screwdriver to easily adjust the ON and OFF time you need. With LED indication for output status. Compact plastic case and wires connects for easy mount. Two screw mounting holes are convenient for you to fix it on the wall or wooden board. Of course, you can also choose not to lock the screw.

AC 100-240V 3Amp Blinking Flasher Module
