Artículo: AMZ-B09476L2BG

Rigol

Rigol DG2052 Function/Arbitrary Waveform Generator 50MHz,2 Channels,16 bit Vertical Resolution,16Mpts Arbitrary Wave Length

Detalles del producto
Disponibilidad
En stock
Peso con empaque
3.37 kg
Devolución
Condición
Nuevo
Producto de
Amazon
Viaja desde
USA

Sobre este producto
  • Rigol DG2052 Function/Arbitrary Waveform Generator With frequencies up to 50 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts.The DG2052 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market.
$1.342,65
49% OFF
$688,54

Producto no disponible

Este producto no está permitido por la aduana del país en categoria 4x4

Este producto viaja de USA a tus manos en

Conoce más detalles

Max. output frequency 50MHz,2 output channels Sample rate up to 250 MSa/s, vertical resolution 16 bits 4.3'' TFT color touch screen RS232, PRBS, and Dual-tone outputs supported Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps 16 Mpts memory depth per channel for arbitrary waveforms Standard dual-channel with the same performance, equivalent to two independent signal sources High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz Built-in high-order harmonic generator (at most 8-order harmonics) Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fi elds Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM
