Hyuduo Stepper Motor Driver Controller, Integrated Board with LCD Display for Speed Delay Cycles Control, CW CCW Pulse Angle Control Module for 42 57 86 Motor 6.6A
Disponibilidad:
En stock
En stock
Peso con empaque:
0.33 kg
0.33 kg
Devolución:
No
No
Condición
Nuevo
Nuevo
Producto de:
Amazon
Amazon
Sobre este producto
- [High Definition Lcd Display] The clear lcd screen provides real time feedback on speed, delay, and cycle count, making it easy to browse and adjust parameters. this feature ensures you have complete control over your motor's performance at all times.
- [Integrated Control and Driver] This stepper motor driver controller combines the functions of both a controller and a driver, allowing you to not only power the motor but also monitor and adjust its working status in real time. perfect for applications requiring precise and dynamic control.
- [Multi Directional Control] Change the rotation direction effortlessly using the built in buttons or the potentiometer. the controller automatically adjusts the direction based on the selected working mode, making it ideal for versatile applications across different scenarios.
- [Precise and Reliable Control] Achieve accurate motor control with parameters that support memory function, ensuring your settings are saved and not lost. this reliability is for consistent performance in repetitive tasks.
- [9 Default Workflow Programs] The integrated controller comes with 9 pre set workflow programs, covering a wide range of applications. features include cw, ccw, delay, loop self locking, non lock, and rotational speed adjustments, making it suitable for diverse industrial needs.
AR$105,802
49% OFF
AR$54,261
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
AR$105,802
49% OFF
AR$54,261
Pagá fácil y rápido con Mercado Pago o MODO
Llega en más de 28 días hábiles
con envío
Tienes garantía de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Compra protegida
Disfruta de una experiencia de compra segura y confiable
Tarjetas de Crédito y Débito
Visa
Mastercard
American Express
Pagos a través de PayPal
Compra procesada en dólares con dinero en cuenta o tarjetas internacionales.
Paypal
Pagos a través de MODO
Compra procesada en pesos desde la App de tu banco.
PayPal
Conoce más detalles
Specification: Item Type: Stepper Motor Driver Controller Product Model: XY-SMD6 Applicable Motor Types: 42, 57, 86 stepper motors Number of Control Axes: Single axes Motor Signal: Common negative Driving Capacity: 6.6A Acceleration And Deceleration Control: Yes Input CCW Connection Protecting: Yes High Temperature Protecting: Yes Active Cooling: Yes, the fan starts when the temperature exceeds 55℃ and stops when it drops below 50℃ Communication Interface: Serial port TTL(standard support for MODBUS protocol) System Main Functions: Automatic, manual, setting, and serial port control Pulse Frequency Range: 100HZ to 80,000Hz Speed Rating Range: 0-1000 CW Stroke: 9999.999mm CCW Stroke: 9999.999mm Loop Operating Times: 1-9999, -- represents loop CW Delay Time: 0.000-9999.000 seconds CCW Delay Time: 0.000-9999.000 seconds Subdivision Selection Range: 8-64 Subdivisions Operating Temperature: -5 to 60℃(no condensation) Material: ABS How to Use: Can be used directly after being taken out. packing list: 1 x Control Driver 1 x Accessory
